Multiaxial Carbon Fiber for Composite Reinforcement

Basic Info.

Fiber Length	Custom Length, Custom Length
Fiber Diameter	7μm, 7μM
Applications	Marine, Marine
Fabric Type	Plain Weave, Plain Weave
Area Weight	200/400GSM
Construction	0/90 or +/-45 Degree
Carbon Fiber	12K
Roll Width	1270mm
Transport Package	in Carton
Specification	12k
Trademark	JLON
Origin	China
HS Code	68159920
Production Capacity	100000 M2

Product Description

Introduction: Carbon fabric is light weight, high strength and high modulus. It has good resistance to fatigue, heat and corrosion. Our multiaxial carbon fiber cloth include biaxial in 0/90 and +/-45 degree. Basically, these are UD fabrics with fiber orientations of 0/90 or +/-45 stitched together.

Typical Uses: aviation, automobile, bicycle, surfboard, suite case, reinforcement to helmet, buildings…

Technical Parameters:

Fabric Specification	Total Weight (g/m2)	0°	90°	+45°	-45°	Stitching Yarn (g/m2)	Binder(g/m2)
C-PN600-12	602			300	300	2
C-PN600-50	602			300	300	2
C-LT400-12	402	200	200			2
C-LT600-50	602	300	300			2
C-TX500-12	502	200		150	150	2
C-QX600-12	602	150	150	150	150	2
C-L150-12-B	174	150	12			4	8
C-P150-12-B	176			150	10	8	8
C-N150-12-B	176			10	150	8	8
C-L300-50-B	326	300	12			4	10
C-P300-12-B	328			300	10	8	10
C-N300-12-B	328			10	300	8	10
C-L600-50-B	628	600	12			4	12
C-PN260-12	262			130	130	2
C-LT260-12	262	130	130			2
C-PN400-12	402			200	200	2
C-QX400-12	402	100	100	100	100	2
